EMEC Precision Dosing Pumps
Precision dosing pumps — often called metering pumps — are highly accurate positive displacement systems that combine advanced microprocessors with tough, chemically resistant materials. Whether handling municipal water treatment or complex automated process control, these systems are the industry standard for exact, highly accurate chemical injection.
EMEC Innovation Partner: Cyclone is a proud partner to EMEC Pumps in Italy. Since 1982, EMEC has been designing and producing reliable, cutting-edge instruments for water treatment and chemical dosage, rooted in constant research, extreme precision, and healthy relationships.
Product Overview
EMEC Precision Dosing Pumps represent the pinnacle of chemical metering technology. These are not your average fluid movers; they are highly accurate positive displacement pumps engineered for applications where precision, reliability, and automation are non-negotiable. Whether you’re handling municipal water treatment, complex chemical processes, or automated facility control systems, EMEC dosing pumps deliver repeatable accuracy and integrated intelligence that eliminate guesswork from chemical management.
Built on a foundation of constant research and engineering precision, each EMEC system combines proven mechanical reliability with advanced microprocessor control. The result is a solution that adapts seamlessly to your process — whether you need fractional millilitre-per-hour precision or full-volume capacity — all through a single, intelligently controlled unit.
Drive Mechanisms & Control Architectures
Solenoid-Driven Diaphragms
Think of this architecture as a rapid, pulsing electromagnet. When the coil is energised, it magnetically pulls an armature connected to the pump diaphragm, creating a discharge stroke that forces fluid out. A heavy-duty spring then snaps the armature back, creating a vacuum to draw in the next micro-dose. It’s incredibly fast, repeatable, and reliable — ideal for applications requiring rapid response and high duty-cycle operation.
Stepper Motor Drives
This is where advanced automation meets mechanical precision. Using a microprocessor-controlled stepper motor tied to a mechanical cam, you get infinite control over the stroke profile. The pump can execute a quick suction stroke followed by a slow, highly controlled discharge — delivering continuous, nearly pulsation-free delivery that is absolutely perfect for highly viscous liquids or chemicals that tend to off-gas.
Wet-End Architecture & Chemical Resistance
Because these pumps handle aggressive and corrosive fluids like sodium hypochlorite, sulphuric acid, and polymers, the “wet end” – the part that actually touches the fluid — is engineered to be practically bulletproof.
Pump Heads
The universal standard is usually machined or moulded PVDF, but depending on your thermal or solvent requirements, they can also be manufactured from PTFE (Teflon), Polypropylene, or 316L Stainless Steel, ensuring compatibility with virtually any chemical application.
Diaphragms
These are almost always engineered from solid PTFE. It delivers maximum flexibility and chemical resistance, allowing the pump to handle millions of cycles without wear or degradation.
Check Valves
To prevent messy backflow or siphoning, these pumps use precision double-ball check valves on both the suction and discharge sides. The valve balls are usually made from high-density ceramic, glass, or PTFE, and they sit snugly on chemical-specific O-rings like Viton or EPDM.
Advanced Control & Automation
Modern EMEC dosing pumps are far more than simple mechanical pushers; they act as intelligent nodes in your process, ready to integrate seamlessly into automated environments.
Proportional Dosing
Thanks to onboard microprocessors, the pump can automatically adjust its stroke rate based on external analog signals — such as a standard 4–20 mA from a flow metre – or digital pulse inputs, delivering dynamic, demand-responsive chemical injection.
Integrated Process Control
Many higher-end units feature built-in PID controllers. They can read sensor inputs — like pH, ORP, Conductivity, or Chlorine – and autonomously adjust their own dosing rates to maintain your exact chemical setpoint without needing a separate PLC, dramatically simplifying facility control.
Extreme Turndown Ratios
High-end models offer turndown ratios of 1:3000 or more. This means you can use the exact same pump to push maximum capacity or deliver just a few careful millilitres per hour, eliminating the need for multiple pump investments.
Performance Specifications
Typical Applications
- Municipal and industrial water treatment — pH neutralisation, coagulation, flocculation, chlorination
- Food and beverage processing — Clean-in-Place chemical dosing, enzyme injection, preservative addition
- Agriculture — automated fertigation and precise hydroponic nutrient dosing
- Cooling towers and boiler systems — biocide, anti-scalant, and corrosion inhibitor injection
- Chemical processing facilities — precision reactant and additive dosing
- Pharmaceutical and laboratory automation — sterile and ultra-precise chemical handling
